MS Chart Tutor -1 : Asp.net

Posted by A IT Devotee on Thursday, May 14, 2009

In this article we are going to study the basic chart to use in aspx pages.

It is a basic chart formation in aspx pages.

Previous articles :
how to install MSchart and to configure to VS 2008.

Source code download

http://sites.google.com/site/novadwnload/basicchart-tutor-1



ASPX Code



<%@ Page Language="C#" AutoEventWireup="true" CodeFile="UserOnline.aspx.cs" Inherits="Roles_AdminNew_Charts_UserOnline" %>

<%@ Register Assembly="System.Web.DataVisualization, Version=3.5.0.0, Culture=neutral, PublicKeyToken=31bf3856ad364e35"
    Namespace="System.Web.UI.DataVisualization.Charting" TagPrefix="asp" %>

<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd">

<html xmlns="http://www.w3.org/1999/xhtml">
<head runat="server">
    <title></title>
    <link href="Common/_assets/css/Corner.css" rel="stylesheet" type="text/css" />

</head>
<body>
    <form id="form1" runat="server">
    <div>

      <div class="dialog">

 <div class="hd">
  <div class="c"></div>
 </div>

 <div class="bd">
  <div class="c">

    <div style="text-align:center;">
       New cool charts

    </div>
    <div style="text-align:center;">
       <asp:Chart ID="Chart1" runat="server" Height="174px" Width="189px"
            BackImage="~/Common/_assets/img/bg.jpg">
            <BorderSkin BackColor="Black" />
            <series><asp:Series Name="Series1"></asp:Series></series>
            <chartareas>
            <asp:ChartArea Name="ChartArea1" ShadowColor="Gray"></asp:ChartArea></chartareas>
        </asp:Chart>
    </div>

  </div>
 </div>
 <div class="ft">
  <div class="c"></div>
 </div>
</div>
    </div>
    </form>
</body>
</html>







Aspx.cs Code




using System;
using System.Collections.Generic;
using System.Linq;
using System.Web;
using System.Web.UI;
using System.Web.UI.WebControls;
using System.Web.UI.DataVisualization.Charting;

public partial class Roles_AdminNew_Charts_UserOnline : System.Web.UI.Page
{
    protected void Page_Load(object sender, EventArgs e)
    {
        Series series = new Series("Spline");
        series.ChartType = SeriesChartType.Bar;
        series.BorderWidth = 3;
        series.ShadowOffset = 2;
        // Populate new series with data
        series.Points.AddY(67);
        series.Points.AddY(57);
        series.Points.AddY(83);
        series.Points.AddY(23);
        series.Points.AddY(70);
        series.Points.AddY(60);
        series.Points.AddY(90);
        series.Points.AddY(20);
        // Add series into the chart's series collection
        Chart1.Series.Add(series);
        string a = Utilities.Crawl("http://google.com");

    }
}




For rounded corner
http://docs.jquery.com/Tutorials:Rounded_Corners#Example_And_Code
